5. Managing Disks
The V2616A-LX computers come with a software-RAID management platform designed to serve as a front-end
for data acquisition and industrial control applications. This chapter describes how to configure the volume
supported by the Linux operating system.
The following topics are covered in this chapter:
Software RAID --- mdadm
Create Software RAID Volume
Check Software RAID Status
Replace the Failed Disk
