Moxa V2616A-C8-CT-W7E [78/111] V2616a linux system recovery
![Moxa V2616A-C8-CT-W7E [78/111] V2616a linux system recovery](/views2/1200243/page78/bg4e.png)
V2616A Linux System Recovery
7-12
6. Once you have powered down the system and removed the USB drive, you have finished configuring the
recovery environment. The USB drive should be clearly labeled and stored in a safe place. You may now
continue to Step 4: Reset the BIOS to its Original State, or you may go to and test the recovery procedure
for successful configuration (Step 5).
