V2616A Linux Software Components
A-12
libsndfile1 1.0.21-3+squeeze1 Library for reading/writing audio files
libsnmp-base 5.4.3~dfsg-2 SNMP (Simple Network Management Protocol) MIBs
and documentation
libsnmp15 5.4.3~dfsg-2 SNMP (Simple Network Management Protocol) library
libsoup-gnome2.4-1 2.30.2-1 an HTTP library implementation in C -- GNOME support
library
libsoup2.4-1 2.30.2-1 an HTTP library implementation in C -- Shared library
libspeex1 1.2~rc1-1 The Speex codec runtime library
libsqlite3-0 3.7.3-1 SQLite 3 shared library
libss2 1.41.12-4stable1 command-line interface parsing library
libssl0.9.8 0.9.8o-4squeeze1 SSL shared libraries
libstartup-notification0 0.10-1 library for program launch feedback (shared library)
libstdc++6 4.4.5-8 The GNU Standard C++ Library v3
libstdc++6-4.4-dev 4.4.5-8 The GNU Standard C++ Library v3 (development files)
libtag1-vanilla 1.6.3-1 TagLib Audio Meta-Data Library (Vanilla flavour)
libtag1c2a
1.6.3-1
TagLib Audio Meta-Data Library
libtalloc2 2.0.1-1 hierarchical pool based memory allocator
libtasn1-3 2.7-1 Manage ASN.1 structures (runtime)
libtdb1 1.2.1-2+b1 Trivial Database - shared library
libtext-charwidth-perl 0.04-6 get display widths of characters on the terminal
libtext-iconv-perl 1.7-2 converts between character sets in Perl
libtext-wrapi18n-perl 0.06-7 internationalized substitute of Text::Wrap
libthai-data 0.1.14-2 Data files for Thai language support library
libthai0 0.1.14-2 Thai language support library
libtheora0 1.1.1+dfsg.1-3 The Theora Video Compression Codec
libtie-ixhash-perl 1.21-2 ordered associative arrays for Perl
libtiff4 3.9.4-5+squeeze3 Tag Image File Format (TIFF) library
libtimedate-perl 1.2000-1 collection of modules to manipulate date/time
information
libtokyocabinet8 1.4.37-6 Tokyo Cabinet Database Libraries [runtime]
libtotem-plparser17
2.30.3-1
Totem Playlist Parser library - runtime files
libtracker-client-0.8-0 0.8.17-1 metadata database, indexer and search tool - library
libtwolame0 0.3.12-1 MPEG Audio Layer 2 encoding library
libudev0 164-3 libudev shared library
libunique-1.0-0 1.1.6-1.1 Library for writing single instance applications - shared
libraries
libupower-glib1 0.9.5-5 abstraction for power management - shared library
liburi-perl 1.54-2 module to manipulate and access URI strings
libusb-0.1-4 2:0.1.12-16 userspace USB programming library
libusb-1.0-0 2:1.0.8-2 userspace USB programming library
libusbmuxd1 1.0.4-1 USB multiplexor daemon for iPhone and iPod Touch
devices - library
libuuid-perl 0.02-4 Perl extension for using UUID interfaces as defined in
e2fsprogs
libuuid1 2.17.2-9 Universally Unique ID library
libv4l-0
0.8.0-1
Collection of video4linux support libraries
libvisual-0.4-0 0.4.0-3 Audio visualization framework
libvisual-0.4-plugins 0.4.0.dfsg.1-2 Audio visualization framework plugins
libvorbis0a 1.3.1-1 The Vorbis General Audio Compression Codec
(Decoder library)
libvorbisenc2 1.3.1-1 The Vorbis General Audio Compression Codec
(Encoder library)
libvorbisfile3 1.3.1-1 The Vorbis General Audio Compression Codec (High
