7. System Recovery
The V2616A-LX ready-to-run embedded computers are an embedded Linux platform. This chapter describes
the recovery process in the event of system instability.
The following topics are covered in this chapter:
Overview
Setting Up the Recovery Environment
Recovering from the Factory Default Image
Step 1: Prepare the USB Drive
Step 2: Setting the BIOS to Boot via USB
Step 3: Performing a System Recovery
Step 4: Reset the BIOS to its Original State
Creating a Custom System Image
