18
4. Playback Data
The Playback Data function allows viewing data from last test
recorded by the scan tool.
NOTE: The amount of files that can be saved depends on the
space available in the SD card.
4.1 Reviewing Data
1) Use the LEFT/RIGHT scroll button to select Playback from
Main Screen (Figure 3.1), and press the OK button. Wait for
the Replay screen to appear.
Figure 4.1
2) To review data saved in the scan function, select Scan in the
Replay menu. To review data saved in the EPB function, select
EPB in the Replay menu. Then press OK button to continue.
3) Use the UP/DOWN scroll button to select the desired item from
Scan menu or EPB menu, and press the OK button.
Figure 4.2
Replay
1.EPB
2.Scan
Scan
1. UITrouble
/scan/MAKE/USA/FORD/
2. UIDatastream: complete list
/scan/make/EOBD/
3. UIFreeze
/scan/make/USA/
Delete Delete All
