Autel MaxiCheck PRO [71/76] In the epb screen use the up down button to select electric parking brake replacement the screen shows as below
![Autel MaxiCheck PRO [71/76] In the epb screen use the up down button to select electric parking brake replacement the screen shows as below](/views2/1200933/page71/bg47.png)
69
Figure 8.15
If the job fails to finish, the tool will display a message to remind
user of a problem. After you exit the diagnosis program, please
repair the problem immediately.
Figure 8.16
3) In the EPB screen, use the UP/DOWN button to select
Electric parking brake replacement. The screen shows as
below.
Figure 8.17
Electric parking brake calibration
Electric parking brake cable
calibration done!
Press any key to continue
Electric parking brake calibration
Activation done, a problem
occurred during the operation.
Press any key to continue
OK
Electric parking brake replacement
1.Put in fitting/removal position
2.Cable tensioning
3.Electric parking brake
calibration.
