4) View test results of selected O2 sensor. (Figure 5.25)

Figure 5.25

5) Use the UP/DOWN scroll button to view more screens of data if

additional information is available in more than one page.

6) Press the ESC button to return to the previous menu.

5.7. On-Board Monitor Test

The On-Board Monitor Test is useful after servicing or after

erasing a vehicle‟s control module memory. The On-Board

Monitor Test for non-CAN-equipped vehicles retrieves and

displays test results for emission-related power train components

and systems that are not continuously monitored. The On-Board

Monitor Test for CAN-equipped vehicles retrieves and displays

test results for emission-related power train components and

systems that are and are not continuously monitored. Test and

components IDs are determined by the vehicle manufacturer.

In this test, there are typically a minimum value, a maximum value,

and a current value for each monitor. By comparing the current value

with the minimum and maximum value, the scan tool will determine

if it is OK.

1) Use the UP/DOWN scroll button to select On-Board Monitor

Test from Diagnostic Menu and press the OK button. (Figure

5.3)

2) Wait a few seconds while the scan tool validates the PID MAP.

… ……… .O2 Bank1 Sensor2 .

Rich-Lean Threshd V

Lean-Rich Threshd V

Low for Switch (V)

High for Switch (V)

Rich-Lean Threshd S

Lean-Rich Threshd S
