Autel MaxiCheck PRO [68/76] B cable tensioning

Figure 8.7

If the job fails to finish, the tool will display a message to remind

user of a problem. After you exit the diagnosis program, please

repair the problem immediately.

Figure 8.8

B. Cable tensioning

Once the brake cable is fit in, you would use this function to

adjust its tension. It will take a few seconds to execute this

command.

Figure 8.9

Put in fitting/removal position

Positioning done.

To replace or remove the brake

cables, refer to the mechanical

schedule "Removal-replacement:

electric parking brake primary and

secondary cables"

Press any key to continue

Put in fitting/removal position

Activation done, a problem

occurred during the operation.

Press any key to continue

Cable tensioning

Activation in progress!
