![Autel MaxiCheck PRO [75/76] Active test](/views2/1200933/page75/bg4b.png)
73
2) In the EPB menu, select the desired function and press OK
button. If the operation is finished successfully, the scan tool
will display a confirmation message. Otherwise, it will display
a message to remind user of a problem. After you exit the
diagnosis program, please repair the problem immediately.
Active Test
1) In the Diagnostic Menu (Figure 8.20), use the UP/DOWN
button to select Active Test to do the actuator test. The scan
tool displays as below.
Figure 8.22
2) In the Active menu, use the UP/DOWN button to select the
desired actuator to begin test. If the selected actuator works
correctly, the tool will display a confirmation message as
below (Figure 8.23). Otherwise, it will display a message to
remind user of a problem. After you exit the diagnosis program,
please repair the problem immediately.
Figure 8.23
Active
1.ABS/ASR recirculation pump
2.Left front intake solenoid valve
3.Right front intake solenoid valve
4.Left rear intake solenoid valve
5.Right rear intake solenoid valve
6.Switching solenoid valve 1
7.Switching solenoid valve 2
Active
Operation completed!
No fault detected!
Press any key to continue
