Руководство пользователя Страница: 70

Autel MaxiCheck PRO [70/76] After you select this function the tool will automatically work in the following procedure

After you select this function, the tool will automatically work in

the following procedure.

Figure 8.12

Figure 8.13

Figure 8.14

When the job is done successfully, the tool will display a

message to confirm.

Electric parking brake calibration

Activation in progress!

Electric parking brake calibration

Please wait! The tool should stop

and restart the communication

with the Electric parking brake

ECU.

Electric parking brake calibration

Restart communication
