In the Electric parking brake replacement screen, the tool can
also perform three functions, which details could refer to the
same functions described in the Brake cable replacement menu
above.
Active Test
During an active test, the tool is used for outputting commands to the
ECU in order to drive the actuators. This test determines the integrity
of the system or parts by monitoring the operation of the actuators or
by reading the EPB ECU data.
To carry out an active test, please follow these steps.
1. Follow the instructions above to display the Diag. menu
screen.(Figure 8.3)
2. Select Active Test and a list of possible tests appear. The test
items in the list vary with different vehicles.
Figure 8.18
3. Select a test and the tool will display an information screen as
“The 'apply electric parking brake' operation is used to test
the operation of the brake cables statically. If you start the
actuator test, you must wait for the component to stop
operating before starting another actuator test. Press 'OK'
to apply the electric parking brake or press 'Cancel' to go
back to the list of possible operation.” Select OK to continue
or Cancel to exit.
Active
1.Apply electric parking brake
2.Release electric parking brake
