44
Figure 5.39
3) Select Show and a soft keyboard will pop up. Use
LEFT/RIGHT button and UP/DOWN button to move to the
desired character, then press OK button to confirm.
4) After you input the DTC code, select Finish and the scan tool
will display this code’s definition on screen.
Figure 5.40
5) Press Yes or OK button to proceed. The scan tool will display
DTC definition as below.
Figure 5.41
DTC Lookup
Only PCBU can be the first letter
to be put in. Only 0~9,a~f for the
rest letters...
Finish Show Esc
Trouble Codes
P0005
Fuel Shutoff Valve A Control
Circuit/Open
Save
Input Dialog Box
P0005
Do you want to save and
continue?
Yes No
