Autel MaxiCheck PRO [31/76] Recording data
![Autel MaxiCheck PRO [31/76] Recording data](/views2/1200933/page31/bg1f.png)
29
Figure 5.14
The number to the right of selected item indicates sequence
of this item.
If you want to deselect the item, press Clear button.
To select all the items on the screen, press Select All button.
To clear all the selected items on the screen, press Clear All
button.
3) Press the OK button to view selected PIDs on screen.
Figure 5.15
4) Use the ESC button to return to previous menu.
Recording Data
The Record Data function allows recording vehicle modules‟
Parameter Identification (PID) data to help diagnose
intermittent vehicle problems. You could save data files to the
………… ..Custom List
Numbers of DTCs
1
Fuel system 1 status
2
Fuel system 2 status
Calculated load value
Engine coolant temp
Select All Clear Clear all
Custom List
Numbers of DTCs
0
Fuel system 1 status
OL
Pause Graphics Save
