3) The scan tool will prompt you to select the vehicle make.

Figure 5.26

4) After you select the vehicle manufacturer, the scan tool shows

the On-Board Monitors tests for specific monitoring systems.

5) From On-Board Monitor Test menu, use the UP/DOWN scroll

button to select a test to view and press the OK button. (Figure

5.27)

Figure 5.27

 If the vehicle under test does not support the mode, an

advisory message will be displayed on the screen. (Figure

5.28)

On-Board Monitor Test

1. Test $01 Data

2. Test $03 Data

3. Test $10 Data

4. Test $21 Data

5. Test $22 Data

6. Test $25 Data

Vehicle Manufacturer 1/28

BUICK

BMW

CADILLAC

CHRYSLER

FORD
