22
codes, or trouble codes that have been stored in the vehicle
computer memory because the faults have reoccurred for
more than a specified amount of key-cycles. These codes will
cause the control module to illuminate the malfunction
indicator light (MIL) when emission-related fault occurs.
Pending Codes are also referred to as “maturing codes” or
“continuous monitor codes”. They indicate problems that the
control module has detected during the current or last driving
cycle but are not considered serious yet. Pending Codes will
not turn on the malfunction indicator lamp (MIL). If the fault
does not occur within a certain number of warm-up cycles, the
code clears from memory.
Permanent Codes are DTCs that are "confirmed" and are
retained in the non-volatile memory of the computer until the
appropriate monitor for each DTC has determined that the
malfunction is no longer present and is not commanding the
MIL on. Permanent DTC shall be stored in non-volatile
memory and may not be erased by any diagnostic services or
by disconnecting power to ECU.
1) Use UP/DOWN scroll button to select Read Codes from
Diagnostic Menu and press OK button. (Figure 5.3 )
Figure 5.3
2) Use the UP/DOWN scroll button to select Stored Codes or
Pending Codes from the Read Codes menu and press the OK
button. (Figure 5.4 )
Diagnostic Menu
1.System Status
2.Read Codes
3. Erase Codes
4. Live Data
5.Freeze Frame
6.I/M Readiness
7.O2 Monitor Test
8.On-Board Monitor Test
