Theoretically, all programs in latest versions will be automatically

compatible with the older versions, but if your scan tool do have a

compatible problem and want to retrieve the older version for some

programs, you may need to delete them first then install the older

version again. Choose older version from the pull-down menu of

program version.

Figure 6.6
