63
2) Release the park brake and make sure the car is properly
blocked.
3) Connect the tool to vehicle and power on.
4) Turn the ignition on.
5) Select EPB icon in the Main Screen (Figure 3.1) and wait for
the vehicle manufacturer screen. Choose the correct vehicle
make. (Take PEUGEOT as an example)
Figure 8.1
6) After you have selected the vehicle make, the electric parking
brake system screen will display as below.
Figure 8.2
7) In the electric parking brake system screen, use the UP/DOWN
button to select EPB to enter EPB system. In the EPB
diagnostic function, the tool can read codes, erase codes, record
live data, read ECU information, perform active test, and
perform special function. For the functions already being
System
1.EPB
2.ABS
