ioLogik E2200 Series Modbus/TCP Address Mappings
I-8
1xxxx Read Only Coils (Function 2)
Reference Address Data Type Description
10001 0x0000 1 bit CH0 DI Value
10002 0x0001 1 bit CH1 DI Value
10003 0x0002 1 bit CH2 DI Value
10004 0x0003 1 bit CH3 DI Value
10005 0x0004 1 bit CH4 DI Value
10006 0x0005 1 bit CH5 DI Value
10007 0x0006 1 bit CH6 DI Value
10008 0x0007 1 bit CH7 DI Value
10009 0x0008 1 bit CH8 DI Value
10010 0x0009 1 bit CH9 DI Value
10011 0x000A 1 bit CH10 DI Value
10012 0x000B 1 bit CH11 DI Value
3xxxx Read Only Registers (Function 4)
Reference Address Data Type Description
30001 0x0000 word CH0 DI Count Value Hi-Byte
30002 0x0001 word CH0 DI Count Value Lo-Byte
30003 0x0002 word CH1 DI Count Value Hi-Byte
30004 0x0003 word CH1 DI Count Value Lo-Byte
30005 0x0004 word CH2 DI Count Value Hi-Byte
30006 0x0005 word CH2 DI Count Value Lo-Byte
30007 0x0006 word CH3 DI Count Value Hi-Byte
30008 0x0007 word CH3 DI Count Value Lo-Byte
30009 0x0008 word CH4 DI Count Value Hi-Byte
30010 0x0009 word CH4 DI Count Value Lo-Byte
30011 0x000A word CH5 DI Count Value Hi-Byte
30012 0x000B word CH5 DI Count Value Lo-Byte
30013 0x000C word CH6 DI Count Value Hi-Byte
30014 0x000D word CH6 DI Count Value Lo-Byte
30015 0x000E word CH7 DI Count Value Hi-Byte
30016 0x000F word CH7 DI Count Value Lo-Byte
30017 0x0010 word CH8 DI Count Value Hi-Byte
30018 0x0011 word CH8 DI Count Value Lo-Byte
30019 0x0012 word CH9 DI Count Value Hi-Byte
30020 0x0013 word CH9 DI Count Value Lo-Byte
30021 0x0014 word CH10 DI Count Value Hi-Byte
30022 0x0015 word CH10 DI Count Value Lo-Byte
30023 0x0016 word CH11 DI Count Value Hi-Byte
30024 0x0017 word CH11 DI Count Value Lo-Byte
// for Citect SCADA compatibility, I/O data can be WORD accessed as well
312289 0x3000 word CH0 DI Value
312290 0x3001 word CH1 DI Value
312291 0x3002 word CH2 DI Value
312292 0x3003 word CH3 DI Value
312293 0x3004 word CH4 DI Value
312294 0x3005 word CH5 DI Value
312295 0x3006 word CH6 DI Value
312296 0x3007 word CH7 DI Value
