ioLogik E2200 Series Modbus/TCP Address Mappings
I-26
Reference Address Data Type Description
40049 0x0030 word CH0 DO mode
0: DO 1: pulse
40050 0x0031 word CH1 DO mode
0: DO 1: pulse
40051 0x0032 word CH2 DO mode
0: DO 1: pulse
40052 0x0033 word CH3 DO mode
0: DO 1: pulse
40053 0x0034 word CH4 DO mode
0: DO 1: pulse
40054 0x0035 word CH5 DO mode
0: DO 1: pulse
40055 0x0036 word CH6 DO mode
0: DO 1: pulse
40056 0x0037 word CH7 DO mode
0: DO 1: pulse
40057 0x0038 word CH8 DO mode
0: DO 1: pulse
40058 0x0039 word CH9 DO mode
0: DO 1: pulse
40059 0x003A word CH10 DO mode
0: DO 1: pulse
40060 0x003B word CH11 DO mode
0: DO 1: pulse
40061 0x003C word CH0 DI count filter
40062 0x003D word CH1 DI count filter
40063 0x003E word CH2 DI count filter
40064 0x003F word CH3 DI count filter
40065 0x0040 word CH4 DI count filter
40066 0x0041 word CH5 DI count filter
40067 0x0042 word CH6 DI count filter
40068 0x0043 word CH7 DI count filter
40069 0x0044 word CH8 DI count filter
40070 0x0045 word CH9 DI count filter
40071 0x0046 word CH10 DI count filter
40072 0x0047 word CH11 DI count filter
40073 0x0048 word CH0 DI mode
0: DI
1: count
Other: return illegal data value
40074 0x0049 word CH1 DI mode
0: DI
1: count
Other: return illegal data value
40075 0x004A word CH2 DI mode
0: DI
1: count
Other: return illegal data value
40076 0x004B word CH3 DI mode
0: DI
1: count
Other: return illegal data value
