ioLogik E2200 Series Modbus/TCP Address Mappings
I-22
Reference Address Data Type Description
00123 0x007A 1 bit CH2 DI power-on status
0: off 1: on
00124 0x007B 1 bit CH3 DI power-on status
0: off 1: on
00125 0x007C 1 bit CH4 DI power-on status
0: off 1: on
00126 0x007D 1 bit CH5 DI power-on status
0: off 1: on
00127 0x007E 1 bit CH6 DI power-on status
0: off 1: on
00128 0x007F 1 bit CH7 DI power-on status
0: off 1: on
00129 0x0080 1 bit CH8 DI power-on status
0: off 1: on
00130 0x0081 1 bit CH9 DI power-on status
0: off 1: on
00131 0x0082 1 bit CH10 DI power-on status
0: off 1: on
00132 0x0083 1 bit CH11 DI power-on status
0: off 1: on
00133 0x0084 1 bit CH0 DI safe operate status
0: off 1: on
00134 0x0085 1 bit CH1 DI safe operate status
0: off 1: on
00135 0x0086 1 bit CH2 DI safe operate status
0: off 1: on
00136 0x0087 1 bit CH3 DI safe operate status
0: off 1: on
00137 0x0088 1 bit CH4 DI safe operate status
0: off 1: on
00138 0x0089 1 bit CH5 DI safe operate status
0: off 1: on
00139 0x008A 1 bit CH6 DI safe operate status
0: off 1: on
00140 0x008B 1 bit CH7 DI safe operate status
0: off 1: on
00141 0x008C 1 bit CH8 DI safe operate status
0: off 1: on
00142 0x008D 1 bit CH9 DI safe operate status
0: off 1: on
00143 0x008E 1 bit CH10 DI safe operate status
0: off 1: on
00144 0x008F 1 bit CH11 DI safe operate status
0: off 1: on
00145 0x0090 1 bit CH0 DI set channel
Power-off storage enable on/off
1: on 0: off
00146 0x0091 1 bit CH1 DI set channel
Power-off storage enable on/off
1: on 0: off
00147 0x0092 1 bit CH2 DI set channel
Power-off storage enable on/off
1: on 0: off
