Alpine IVA-D100RB [36/78] Adjusting source signal levels
![Alpine IVA-D100RB [36/78] Adjusting source signal levels](/views2/1205300/page36/bg24.png)
35-EN
01GB05IVA100R.fm
ALPINE IVA-D100R 68-05946Z50-A (EN)
If the difference in volume level between the CD and FM radio is too
great, adjust the FM signal level as follows.
Setting item: FM LEVEL
Setting content: LOW / HIGH
Setting item: PI SEEK
Setting content: OFF / AUTO
When OFF is selected, the unit automatically keeps receiving the related
local RDS station.
Setting item: RDS REGIONAL
Setting content: OFF / ON
You can select one of the patterns of the display languages.
Setting item: PTY LANGUAGE
Setting content: GB / NL / F / D / I / E
PTY31 (Emergency Broadcast) reception can be set to ON/OFF.
Setting item: PTY31
Setting content: ON / OFF
• The unit automatically gives priority to an Emergency Broadcast
whenever it begins, and interrupts the programme you are currently
listening to when PTY31 is set to on.
• The unit will show “ALARM” in the display during PTY31 reception.
When using discs containing both audio data and MP3/WMA data.
Setting item: PLAY MODE
Setting content: CD / CMPM
• If a disc is inserted, remove it from this unit before setting.
• When an MP3-compatible CD changer is used, this setting cannot be
applied.
Two type of font can be selected.
Setting item: LANGUAGE SELECT
Setting content: MODE1 / MODE2
• Russian font display does not apply to RDS mode.
You can adjust the brightness of the button lighting at night with the
dimmer.
Setting item: LED DIMMER LEVEL
Setting level: -2 to +2
• The adjustment is available when ON or AUTO is set in “Setting the
Brightness of the Backlighting” (page 38).
• The adjusted brightness is reflected in the button lighting and guide
indicator. However, if the level is set to “-2”, the guide indicator
turns off.
Adjusting Source Signal Levels
PI SEEK Setting
Receiving RDS Regional (Local) Stations
Switching the Display Language of PTY
(Programme Type)
Setting PTY31 (Emergency Broadcast)
Reception
Playing MP3/WMA Data
CD: Plays only the audio data on discs containing both audio
data and MP3/WMA data.
CMPM:Plays only the MP3/WMA files on discs containing both
audio data and MP3/WMA data.
Changing the Russian Font
MODE1: Usual font display (ISO8859-1)
MODE2: Russian font display (WINDOWS-1251)
Adjusting the Dimmer of Button Lighting at
Night
