43-EN
01GB06IVA100R.fm
ALPINE IVA-D100R 68-05946Z50-A (EN)
6
Touch [] after setting to ON.
The Media Xpander setup screen appears.
7
Touch [] or [] of the desired MX mode.
• Music source (such as radio broadcasts and CDs, excluding MW, LW
radio) level can be set.
MX CD (OFF, CD MX 1 to 3)
CD mode processes a large quantity of data. This data is used
to reproduce the sound cleanly by making use of the data
quantity.
MX CMPM (OFF, CMPM MX 1 to 3)
This corrects information that was omitted at the time of
compression. This reproduces a well-balanced sound close to
the original.
MX FM (OFF, FM MX 1 to 3)
The medium to high frequencies become more clear, and
produces well balanced sound in all the bands.
MX DVD (OFF, MOVIE MX 1 to 2)
The dialogue portion of the video is reproduced more clearly.
MX AUX 1 to 3 (OFF, CMPM MX, MOVIE MX, MUSIC MX)
Choose the MX mode (CMPM, MUSIC, or MOVIE) that
corresponds to the media connected.
8
Touch [RTN] to return to the previous screen.
• The contents of MX set here is reflected to PXA-H700 or PXA-H701.
• When OFF is selected, MX effect of each MX mode will be OFF.
• Each music source, such as radio, CD, and MP3 can have its own
MX setting.
• MX mode does not function when MX is ON for MW, LW radio.
• MX CMPM is applied for MP3/WMA and iPod.
• The MX setting can be performed only when a source is currently
selected.
X-OVER Adjustment
1
Check that Defeat mode is off.
2
Press SETUP.
The SETUP selection screen appears.
3
Touch [] of i-Personalize.
The i-Personalize screen will appear.
4
Touch [] of A.PROCESSOR.
The A.PROC list screen appears.
5
Touch [] or [] of X-OVER to select L/R or L+R.
6
Touch [] of X-OVER.
7
Touch [] of the speaker to be adjusted.
The screen changes to the X-OVER screen to be adjusted.
8
Adjust the crossover to your preference.
Selecting the Cut-Off Frequency
Touch [] or [] of FREQ., then select the cut-off
frequency (crossover point).
The adjustable bandwidth differs depending on the speaker
(channel).
Adjusting the Level
Touch [] or [] of LEVEL, then adjust the HPF or LPF
level.
Adjusting the Slope
Touch [] or [] of SLOPE, then adjust the HPF or LPF
slope.
9
Touch [RTN] to return to the previous screen.
• When the speaker is set to the “OFF” mode, the X-OVER for that
speaker cannot be set. Refer to “Setting the Speakers” (page 42).
• Check the playback frequencies of the connected speakers before
adjusting.
• In order to protect the speakers, there is no OFF setting for the
subwoofer low pass filter (the slope remains the same).
• The H.P.F. filter cannot be set to OFF (slope OFF) if Tweeter is
selected for FRONT1 . Or, only the subwoofer is adjustable if
STEREO is selected for the subwoofer.
Performing Time Correction Manually
(TCR)
Because of the particular conditions inside the vehicle, there can be
major differences in the distances between the various speakers and the
listening position. It is possible to calculate the optimum correction
values and eliminate the time error at the listening position yourself
using this function.
1
Check that Defeat mode is off.
2
Sit in the listening position (the driver’s seat, for
example) and measure the distance (in meters)
between your head and the various speakers.
3
Calculate the difference in distance between the
farthest speaker and the other speakers.
(DVD MUSIC)
This disc contains a large quantity of data such as music clip.
MX uses this data to reproduce the sound accurately.
L/R: Different adjustment values can be set for the left and
right channels.
L+R: Sets the same adjustment values for the left and right
channels.
L = (distance of farthest speaker)
– (distance of other speakers)
01GB00IVAD100R.book Page 43 Friday, February 10, 2006 2:39 PM
