Alpine IVA-D100RB [41/78] Adjusting brightness
![Alpine IVA-D100RB [41/78] Adjusting brightness](/views2/1205300/page41/bg29.png)
40-EN
01GB06IVA100R.fm
ALPINE IVA-D100R 68-05946Z50-A (EN)
You can select a mode suitable for the subject image.
• To return to the initial setting, after selecting any one of the setting
contents (NIGHT M. to CONTRAST) and adjusting a desired
brightness, picture tint, etc., set this function to OFF.
• If your desired brightness, picture tint, etc., are adjusted after
selecting any one of the setting contents (NIGHT M. to CONTRAST),
“CUSTOM” is displayed.
Setting item: BRIGHT
Setting content: -15 ~ +15
You can adjust the brightness between MIN (–15) and MAX
(+15). When it reaches the minimum or maximum point, the
display shows “MIN” or “MAX” respectively.
• When any NIGHT M. to CONTRAST setting item is selected, the
brightness is automatically adjusted according to the car's interior
brightness if AUTO is set in “Setting the Brightness of the
Backlighting” (page 38).
Setting item: COLOR
Setting content: -15 ~ +15
You can adjust the colour between MIN (–15) and MAX (+15).
When it reaches the minimum or maximum point, the display
shows “MIN” or “MAX” respectively.
• Colour adjustment can be made only in the navigation, DVD, Video
CD, AUX modes.
• Colour adjustment cannot be made if a Navigation system with the
RGB feature is connected.
Setting item: TINT
Setting content: G15 ~ R15
Adjust the colour from G15 to R15. “G MAX” or “R MAX” is
displayed at the maximum of each colour.
• Tint adjustment can be made only in the navigation, DVD, Video CD,
AUX modes.
• Tint adjustment cannot be made if a Navigation system with the RGB
feature is connected.
• When the picture from the external input is set to PAL, you cannot
adjust the TINT.
Setting item: CONTRAST
Setting content: -15 to +15
Adjustment of contrast is done in the range of -15 to +15. “HIGH”
and “LOW” appear as the maximum and minimum values
specified.
• When any NIGHT M. to CONTRAST setting item is selected, image
contrast is automatically adjusted according to the car's interior
brightness if AUTO is set in “Setting the Brightness of the
Backlighting” (page 38).
Setting item: SHARP
Setting content: -15 to +15
Adjustment of picture quality is done in the range of -15 to +15.
“HARD” and “SOFT” appear as the maximum and minimum
values specified.
• Picture quality adjustment can be made only in the navigation, DVD,
Video CD, AUX modes.
• Picture quality adjustment cannot be made if a navigation system
with the RGB feature is connected.
You can store the settings made for “Adjusting Image Brightness, Tint,
Depth, Picture Quality and Contrast.”
Setting item: USER PRESET
Setting content: P-1 / P-2
1 After completing “Adjusting Image Brightness, Tint,
Depth, Picture Quality, and Contrast” (page 40), touch
[] or [] of USER PRESET and then select preset
number “P-1” or “P-2” to which the settings are to be
stored.
2 After selecting a preset No., touch [MEMORY].
The adjusted VISUAL EQ mode is stored by the above
operations.
• You can recall the VISUAL EQ mode stored here from P-1 or P-2 of
“Selecting the VISUAL EQ Mode (Maker’s setting)” (page 40).
Selecting the VISUAL EQ Mode (Maker’s
setting)
Setting item: VISUAL EQ
Setting contents: OFF (FLAT) / NIGHT M. / SOFT / SHARP /
CONTRAST / P-1 / P-2
OFF (FLAT): Initial Setting
NIGHT M.: Suitable for movies in which dark scenes
frequently appear.
SOFT: Suitable for CGs and animated films.
SHARP: Suitable for old movies where images are not
clearly shown.
CONTRAST: Suitable for recent movies.
P-1: Recalls the VISUAL EQ mode being stored on
preset No.P-1 from “Storing VISUAL EQ”
(page 40).
P-2: Recalls the VISUAL EQ mode being saved on
preset No.P-2 from “Storing VISUAL EQ”
(page 40).
Adjusting Brightness
Adjusting Colour of Picture
Adjusting Tint of Picture
Adjusting Image Contrast
Adjusting Picture Quality
Storing VISUAL EQ
