Alpine IVA-D100RB [38/78] Adjusting the external input audio level
![Alpine IVA-D100RB [38/78] Adjusting the external input audio level](/views2/1205300/page38/bg26.png)
37-EN
01GB05IVA100R.fm
ALPINE IVA-D100R 68-05946Z50-A (EN)
Setting item: AUX IN
Setting content: OFF / ON / CAMERA / VCR / GAME / TV / DVB-T /
EXT. DVD / EXTPLYR
• OFF is not displayed when the optional DVD player or DVD changer
is connected. During SYSTEM set up, although the AUX name can be
changed, it is not displayed on the source selection screen.
• When OFF is selected, the settings related to AUX cannot be changed
from this unit.
• If "CAMERA" is selected, CAMERA mode name is displayed on the
VISUAL selection screen. When the rear camera is selected even if
the shift lever is not set to reverse (R), the rear picture is output by
selecting CAMERA.
• The selected name is displayed on the VISUAL and REAR selection
screen.
• Only when an Alpine TV tuner is connected, you can operate the
displayed function guide from this unit.
• The selected source name is displayed instead of AUX source name.
Select SOURCE to switch to the guide function of each mode.
However “EXTPLYR” cannot be currently used, but will become
available when the system is expanded in the future.
• When the AUX name other than “CAMERA” is selected on the
Source Select screen, “CAMERA” cannot be selected. If an other
source (Radio, etc.) is selected on the Source Select screen,
“CAMERA” can be selected.
After setting to ON in “Setting the AUX Mode,” this setting can be
carried out.
Setting item: AUX IN LEVEL
Setting content: LOW / HIGH
After setting to ON in “Setting the AUX Mode,” this setting can be
carried out.
Setting item: AUX IN SIGNAL
Setting content: NTSC / PAL
• The video input type can be changed.
Outputs the picture of the source selected on the IVA-D100R/IVA-
D100RB connected to the rear monitor.
Setting item: AUX OUT
Setting content: OFF / ON
Setting item: VISUAL KEY
Setting content: VISUAL / NAV.
Setting item: ILLUM. COLOR
Setting content: GREEN / RED
Setting item: SUBW. OUT
Setting contents: ON / OFF
To connect an audio processor using the optical digital output, set to
“ON” by the following procedure.
Setting item: OPTICAL OUT
Setting contents: OFF / ON
• Afterwards, set ACC to OFF once, then turn it ON again. The setting
of Digital Output is decided.
Setting the AUX Mode
OFF: AUX source is not displayed.
ON: AUX source is displayed.
Adjusting the External Input Audio Level
LOW: Decreases the external input audio level
HIGH: Increases the external input audio level
Switching the Visual Input Signal
Setting the Picture Output
ON: The "REAR SELECT" item is displayed on the SETUP
select screen.
Touch [ ] of REAR SELECT to change to the REAR
select screen, then touch [ ] of the desired source. The
selected source picture is output on the rear monitor.
OFF: The "REAR SELECT" item is not displayed on the SETUP
select screen.
Setting the VISUAL Button
NAV.: Switches directly to the navigation screen by pressing
VISUAL. (Only when an Alpine optional RGB
Navigation is connected.)
VISUAL: Recalls the VISUAL Select screen by pressing
VISUAL.
Changing the Lighting Colour of Buttons
(IVA-D100R only)
GREEN: Lighting colour is green.
RED: Lighting colour is red.
Subwoofer On and Off
ON: Subwoofer output is on.
OFF: Subwoofer output is off.
Setting the Digital Output
01GB00IVAD100R.book Page 37 Friday, February 10, 2006 2:39 PM
