69-EN
01GB07IVA100R.fm
ALPINE IVA-D100R 68-05946Z50-A (EN)
• Set the system switch to “Ai” when only a changer is connected (when the Ai-NET compatible equalizer is not used).
* The label is attached on the bottom of the unit.
CD changer
(Sold Separately)
To plus side of the back
lamp signal lead of the car
(White/Brown)
(Orange/White)
(Blue/White)
(Blue)
(Pink/Black)
(Yellow/Blue)
(Yellow)
(Black)
To supplied power amplifier
(Connect to the REMOTE TURN-
ON lead of page 68.)
REMOTE OUT
REVERSE
REMOTE TURN-ON
POWER ANT
AUDIO INTERRUPT IN
PARKING BRAKE
BATTERY
GND
ACC
(Red)
To remote input lead
To power antenna
To vehicle phone
To the parking brake
signal lead
Battery
Ignition key
Antenna
<Monitor unit>
01GB00IVAD100R.book Page 69 Friday, February 10, 2006 2:39 PM
