41-EN
01GB06IVA100R.fm
ALPINE IVA-D100R 68-05946Z50-A (EN)
Downloading the BACKGROUND data
You can download data (from Alpine’s website) to a CD-R/CD-RW
(data is written in the root folder), and store the data to the IVA-D100R/
IVA-D100RB.
To start BACKGROUND download, access the URL below and follow
the on-screen instructions.
http://www.alpine.com or http://www.alpine-europe.com
or http://www.alpine.com.au
1
Insert the CD-R/CD-RW disc containing the data you
need.
Data search of the disc starts. After completing the data
search, the file selection screen of Data Download is
displayed.
2
Press SETUP.
The SETUP selection screen appears.
3
Touch [] of i-Personalize.
The i-Personalize screen appears.
4
Touch [] of DATA DOWNLOAD.
5
Touch [] or [], then select P-1 or P-2.
The selected wallpaper can be changed.
6
Touch [] or [] to select the desired file name.
7
Touch [MEMORY].
Data download starts.
When data downloading has completed correctly, the
screen returns to the DATA DOWNLOAD screen.
8
Touching [RTN] returns to the previous screen.
• For details about procedures of download, see ALPINE’s Web site.
• If data is newly downloaded, the data overwrites the previous data.
• If the battery power cable is removed, the downloaded data is
memorized.
• You can recall a wallpaper in “Switching Background Textures”
(page 38), or “Setting Automatic Background Textures” (page 38).
• When download has completed, remove the disc.
When an external audio processor is connected to this unit, you can
operate it from this unit. Some audio processors may not be operated. In
this case, operate them in the connected product. Explanations below is
the case when PXA-H700 or PXA-H701 is connected for example.
Refer also to the operating instructions of the connected audio
processor.
• The adjustments or settings performed on the connected audio
processor cannot be operated properly from this unit.
• The setting “Setting the Speakers”, “Setting Bass Sound Control”,
and “Graphic Equalizer Adjustments” are not available if the MRA-
D550 is connected. Additionally, if the MRA-F350 is connected, the
following setting “Setting the MX mode” is not available. Also, the
setting content differs between the PXA-H700 and PXA-H701.
• This unit cannot be connected to the PXA-H510 and PXA-H900.
Data Download External Audio Processor
(Optional)
The Parking Brake must be engaged to access the Audio
Processor mode screen. Attempting to access this screen while
driving will display the warning-CAN’T OPERATE WHILE
DRIVING.
