39-EN
01GB05IVA100R.fm
ALPINE IVA-D100R 68-05946Z50-A (EN)
You can choose from 5 different colours for the font background.
Setting item: BASE COLOR
Setting contents: MODE 1 to MODE 5
You can turn the touch panel’s vibration ON or OFF during operation.
Setting item: PULSETOUCH
Setting content: OFF / ON
Adjustment becomes necessary when the display position on the LCD
and the touch position on the touch panel do not match.
Setting item: SCREEN ALIGNMENT
Setting content: / RESET
1 Touch [] of SCREEN ALIGNMENT.
The adjustment screen appears.
2 Accurately touch the mark provided in the lower left
corner of the screen.
The screen changes to the adjustment screen.
3 Accurately touch the mark provided in the upper right
corner of the screen.
This completes adjustment, and returns to the DISPLAY
setup mode screen.
• If you have touched a location other than the mark, touch
[RESET] to restore the adjustment screen to the initial setting.
• If you touch [RTN] on the adjustment screen, no adjustment is done
and the DISPLAY setup screen is restored.
Visual EQ Setting Operation
1
Press SETUP.
The SETUP selection screen is displayed.
2
Touch [] of i-Personalize.
The i-Personalize setup screen appears.
3
Touch [] of VISUAL EQ.
VISUAL EQ screen appears.
4
Select a desired setting item by touching [] or [].
Setting items:
VISUAL EQ* BRIGHT COLOR* TINT* CONTRAST
SHARP* USER PRESET*
* The setting is available in the visual source mode. (except navigation
screen)
5
Change the setting on the selected item by touching
its [] or [].
6
Touch [RTN] to return to the previous screen.
Switching the Font Background Colour
Turning the Touch Panel Vibration ON or
OFF
OFF: Turns off vibration during operation.
ON: Turns on vibration during operation.
Adjusting the Touch Panel
i-Personalize™
VISUAL EQ™
The Parking Brake must be engaged to access the
i-Personalize mode screen. Attempting to access this screen
while driving will display the warning-CAN’T OPERATE
WHILE DRIVING.
The following steps 1 to 6 are common operations to each
“Setting item” of VISUAL EQ setting. Refer to each section for
details
01GB00IVAD100R.book Page 39 Friday, February 10, 2006 2:39 PM
