En-24

MS-7752 Manboard

Jumpers

JBAT1: Clear CMOS Jumper

There s CMOS RAM onboard that s external powered from a battery located on the

manboard to save system conguraton data. Wth the CMOS RAM, the system can

automatcally boot nto the operatng system (OS) every tme t s turned on. If you want

to clear the system conguraton, set the jumpers to clear the CMOS RAM.

Keep Data Clear Data

1 1

Important

You can clear the CMOS RAM by shortng ths jumper whle the system s o. Afterwards,

open the jumper . Do not clear the CMOS RAM whle the system s on because t wll

damage the manboard.
