CE604 User Manual
2
Features
Local and Remote Units connect at distances up to 60 m using two Cat 5e
cables
Transmit speaker, keyboard, mouse, DDC and one DVI via one Cat5
cable; RS-232, microphone and another DVI by adding a second Cat 5e
cable
Allows access to a computer or KVM installation from a remote console
(up to 60m)
Supports Dual View video source transmission (one PC with two video
output ports)
Audio Enabled – supports stereo speakers and microphone
Supports Real DDC bypass and ATEN default EDID technology – set up
various configurations via hotkeys
RS-232 serial channel – connect to a serial terminal, or serial devices such
as touchscreens and barcode scanners (Baud Rate up to 9600 bps)
Compatible with other ATEN Dual View KVM devices, such as
CS1642A/CS1644A and CS1762A/CS1764A
Superior video quality – up to 1920 x 1200 @ 60 Hz at 30 m; 1024 x 768
@ 60 Hz at 60 m
Supports PC wakeup function via one pushbutton or hotkey
Manual compensation control to adjust video signal quality in order to
compensate for distance
Supports Wide Screen formats
Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage
15KV) and 2KV surge protection
Firmware upgradeable
Rack mountable
