Aten CE604 [11/42] Requirements
![Aten CE604 [11/42] Requirements](/views2/1211210/page11/bgb.png)
Chapter 1. Introduction
3
Requirements
Consoles
Up to 2 DVI monitors
A USB keyboard
A USB mouse
Stereo microphone and stereo speakers (optional)
Computers
The following equipment must be installed on each computer that is to be
connected to the system:
2 DVI ports
USB port for the mouse and keyboard
Microphone and speaker ports (optional)
Cables
For optimal signal integrity, and to simplify the layout, we strongly
recommend that you use ATEN’s high quality custom KVM Cable that is
provided with this package.
Cat 5e cable is required to connect the Local and Remote CE604 Units.
Cable of a lower standard will result in degrading of the video signal. We
strongly recommend using Cat 5e cables. For better quality over longer
distances, we suggest using 2L-2801 (350 MHz) Low Skew Cable
Maximum Cable Distances
Connection Distance
Computer to Local Unit (CE604L) 5 m
Local Unit (CE604L)
to Remote Unit (CE604R)
60 m at 1024 x 768 @ 60 Hz
30 m at 1920 x 1200 @ 60 Hz
Remote Unit (CE604R) to monitor 5 m
