CE604 User Manual
iii
User Information
Online Registration
Be sure to register your product at our online support center:
Telephone Support
For telephone support, call this number:
User Notice
All information, documentation, and specifications contained in this manual are
subject to change without prior notification by the manufacturer. The manufacturer
makes no representations or warranties, either expressed or implied, with respect to
the contents hereof and specifically disclaims any warranties as to merchantability
or fitness for any particular purpose. Any of the manufacturer's software described
in this manual is sold or licensed as is. Should the programs prove defective
following their purchase, the buyer (and not the manufacturer, its distributor, or its
dealer), assumes the entire cost of all necessary servicing, repair and any incidental
or consequential damages resulting from any defect in the software.
The manufacturer of this system is not responsible for any radio and/or TV
interference caused by unauthorized modifications to this device. It is the
responsibility of the user to correct such interference.
The manufacturer is not responsible for any damage incurred in the operation of
this system if the correct operational voltage setting was not selected prior to
operation. PLEASE VERIFY THAT THE VOLTAGE SETTING IS CORRECT
BEFORE USE.
This ATEN product is specifically designed and manufactured for the operation
and management of computer mainframe and communications equipment used in
network management centers. As such, it may not be completely appropriate for
those environments and sites where special standards for performance and high
reliability are required – such as military equipment, traffic management, nuclear
facilities, security systems, communications equipment, medical facilities, etc.
International http://eservice.aten.com
International 886-2-8692-6959
China 86-10-5255-0110
Japan 81-3-5615-5811
Korea 82-2-467-6789
North America 1-888-999-ATEN ext 4988
United Kingdom 44-8-4481-58923
