Aten CE604 [41/42] Specifications
![Aten CE604 [41/42] Specifications](/views2/1211210/page41/bg29.png)
Appendix
33
Specifications
Function CE604L CE604R
Connectors KVM
Ports
USB 1 x USB Type B Female
(White)
N/A
Speakers 1 x Mini Stereo Jack
Female (Green)
N/A
Mic. 1 x Mini Stereo Jack
Female (Pink)
N/A
Video input 2 x DVI-D Female
(White)
N/A
Console
Ports
Video N/A 2 x DVI-D Female
(White)
Speakers N/A 1 x Mini Stereo Jack
Female (Green)
Mic. N/A 1 x Mini Stereo Jack
Female (Pink)
Keyboard N/A 1 x USB Type A Female
(White)
Mouse N/A 1 x USB Type A Female
(White)
RS-232 1 x DB-9 Female (Black) 1 x DB-9 Male (Black)
Power 1 x DC Jack (Black)
Sub / Main 2 x RJ-45 Female (Black)
LEDs Link 1 (Green) 1 (Green)
Power 1 (Green) 1 (Green)
Switches Compensation switch N/A 2 x 8-position switch
F/W Upgrade 1 x Slide Switch N/A
Buttons Wake Up button N/A 1 pushbutton
Video 1920 x 1200 @ 60Hz (30 m);
1024 x 768 @ 60Hz (60 m)
Power Consumption DC5.3V, 3.4W D5.3V, 4.3W
Environment Operating Temp. 0–50ºC
Storage Temp -20–60ºC
Humidity 0–80% RH, Non-condensing
Physical
Properties
Housing Metal
Weight 0.48 kg
Dimensions (L x W x H) 20.20 x 8.54 x 2.50 cm 20.20 x 8.70 x 2.50 cm
