Chapter 3
H110T-SI01 USER MANUAL
33
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Main Advanced Chipset Tweak Security Boot Exit
CPU Temperature (DTS) 41
System Temperature 34
o
C
CPU Fan Speed 726 RPM
System Fan Speed 0 RPM
Core Voltage 0.935V
DIMM Voltage 1.199V
+12V 12.210V
+5V 5.159V
+VCC 5.137V
TCC Activation Temperature (DTS) 100
PC Health Status
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
• CPU Temperature (DTS)
• System Temperature
• CPU Fan Speed
• System Fan Speed
• Core Voltage
• DIMM Voltage
• +12V
• +5V
• +VCC
System Component Characteristics
These items display the monitoring of the overall inboard hardware health events,
such as System temperature, CPU & DIMM voltage, CPU & System fan speed... etc.
Press <Esc> to return to the Advanced Menu page.
