Chapter 3
H110T-SI01 USER MANUAL
46
This page enables you to set setup administrator password and user password.
Security Menu
Main Advanced Chipset Tweak Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
Set Administrator Password
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Administrator Password Status (Not Install)
This item shows administrator password installed or not.
User Password Status (Not Install)
This item shows user password installed or not.
Secure Boot state (Not Active)
This item allows you to enable or disable the secure boot state.
Administrator Password
Administrator Password Status Not Install
User Password Status Not Install
System Mode state Setup
Secure Boot state Not Active
Secure Boot Enabled
Secure Boot Mode Standard
System Mode state (Setup)
This item shows system mode setup or not.
Secure Boot (Enabled)
This item is used to control the secure boot flow, it is possible only if system runs in
User Mode.
Secure Boot Mode (Standard)
This item is used to select the secure boot mode.
