Chapter 3
H110T-SI01 USER MANUAL
38
SATA Configuration
Use this item to show the mode of serial SATA configuration options.
Main Advanced Chipset Tweak Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Determines how SATA
controller(s) operate.
SATA Mode (AHCI)
Use this item to select SATA mode.
SATA Port 1~2/M.2 (Not Present)
This motherboard supports two SATA channels and one M.2 channel, each channel
allows one SATA/M.2 device to be installed. Use these items to configure each
device on the SATA/M.2 channel.
Press <Esc> to return to the Advanced Menu page.
Spin Up Device (Disabled)
Use this item to enable or disable the spin up device.
External SATA (Disabled)
Use this item to enable or disable the external SATA.
SATA Configuration
SATA Mode AHCI
SATAII Port1
Not Present
Spin Up Device Disabled
External SATA Disabled
SATAII Port2
Not Present
Spin Up Device Disabled
External SATA Disabled
M.2
Not Present
