Chapter 3
H110T-SI01 USER MANUAL
36
Number of cores to enable
in each processor package.
Main Advanced Chipset Tweak Security Boot Exit
Intel(R) Core(TM) i5-6500T CPU @ 2.50GHz
This is display-only field and displays the information of the CPU installed in your
computer.
EM64T (Supported)
This item shows the computer supports EM64T.
Processor Speed (2500MHz)
This item shows the current processor speed.
Processor Stepping (506E3)
This item shows the processor stepping version.
Microcode Revision (76)
This item shows the Microcode version.
Processor Cores (4)
This item shows the core number of the processor.
Intel HT Technology (Not Supported)
This item shows the computer not support Intel HT Technology or not.
CPU Configuration
The item in the menu shows the CPU configuration.
Enter/Dbl Click : Select
+/- : Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
ESC/Right Click: Exit
F4: Save & Exit
/Click: Select Item
: Select Screen
Intel VT-x Technology (Supported)
This item shows the computer support Intel VT-x Technology or not.
CPU Configuration
Intel(R) Core(TM) i5-6500T CPU @ 2.50GHz
EM64T Supported
Processor Speed 2500 MHz
Processor Stepping 506E3
Microcode Revision 76
Processor Cores 4
Intel HT Technology Not Supported
Intel VT-x Technology Supported
Active Processor Cores All
Limit CPUID Maximum Disabled
Execute Disable Bit Enabled
Intel Virtualization Technology Enabled
Package C State limit AUTO
Enhanced Halt (C1E) Enabled
HardWare P states (HWP) Disabled
Active Processor Cores (All)
Use this item to control the number of active processor cores.
Intel HT Technology (Not Supported)
This item shows the computer not support Intel HT Technology or not.
