Chapter 3
A85F2-A DELUXE (GOLDEN) USER MANUAL
39
All USB Devices (Enabled)
Use this item to enable or disable all USB devices.
USB Configuration
Use this item to show the information of USB configuration.
Legacy USB Support (Enabled)
Use this item to enable or disable support for legacy USB devices.
Main Advanced Chipset M.I.B X Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
USB Configuration
All USB Devices Enabled
Press <Esc> to return to the Advanced Menu page.
Legacy USB Support Enabled
USB 3.0 Controller Enabled
USB 3.0 Controller (Enabled)
Use this item to enable or disable USB 3.0 Controller.
