5
A85F2-A DELUXE (GOLDEN) USER MANUAL
Chapter 1
Table of Motherboard Components
LABEL COMPONENTS
1. CPU Socket FM2 for AMD TRINITY processors
2. CPU_FAN CPU cooling fan connector
3. DDR3_1~4 240-pin DDR3 SDRAM slots
4. ATX_POWER Standard 24-pin ATX power connector
5. SATA1~7 Serial ATA 6.0 Gb/s connectors
6. F_PANEL Front panel switch/LED header
7. F_USB1(EZ) Front panel USB 2.0 header--F_USB1(EZ) supports EZ Charger
8. F_USB2~3 Front panel USB 2.0 headers
9. CLR_CMOS Clear CMOS jumper
10. USB3F Front panel USB 3.0 header
11. PWR_FAN Power cooling fan connector
12. SYS_FAN System cooling fan connector
13. SPK Speaker header
14. SPDIFO SPDIF out header
15. COM Onboard serial port header
16. F_AUDIO Front panel audio header
17. PCI1~2 32-bit add-on card slots
18. PCIEX16_S PCI Express x8 slot
19. PCIE1~3 PCI Express x1 slots
20. PCIEX16 PCI Express slot for graphics interface
21. ATX12V 8-pin +12V power connector
