Chapter 1
2
A85F2-A DELUXE (GOLDEN) USER MANUAL
CPU
Specifications
• AMD A85XChipset
• Dual-channel DDR3 memory architecture
• 4 x 240-pin DDR3 DIMM sockets support up to 64 GB
• Supports DDR3 2600(OC)/2133(OC)/1866/1600/1333 MHz
DDR3 SDRAM
Memory
• 2 x PCI Express x16 Gen2 slots (The PCIEX16_S runs at x8)
• 3 x PCI Express x1 Gen2 slots
• 2 x PCI slots
Expansion
Slots
Storage
• 1 x D-Sub port (VGA)
• 1 x DVI port
• 1 x DP port
• 1 x HDMI port
• 1 x Clear CMOS Button
• 2 x USB 2.0 ports & 4 x USB 3.0 ports
• 1 x eSATA 3.0 connector
• 1 x RJ45 LAN connector
• 1 x Optical SPIDIFO port
• 1 x Audio port (Line in, Line out, Mic_in Rear)
Rear Panel I/O
LAN
• Socket FM2 for AMD TRINITY processors
• Supports CPU up to 125W TDP
Note: Please go to ECS website for the latest CPU support list.
Note: Please go to ECS website for the latest Memory support list.
• 1 x 24-pin ATX Power Supply connector
• 1 x 8-pin 12V Power connector
• 1 x 4-pin CPU_FAN connector
• 1 x 3-pin SYS_FAN connector
• 1 x 3-pin PWR_FAN connector
• 3 x USB 2.0 headers support additional six USB 2.0 ports
--F_USB1(EZ) supports EZ Charger
• 1 x USB 3.0 header supports additional two USB 3.0 ports
• 7 x SATA 6Gb/s connectors
• 1 x COM header
• 1 x Front Panel audio header
• 1 x Front Panel switch/LED header
• 1 x Speaker header
• 1 x SPDIF out header
• 1 x CLR_CMOS header
Internal I/O
Connectors &
Headers
Audio
• Supported by AMD A85X
• 7 x Serial ATA 6.0 Gb/s Host Controllers
• RAID 0, RAID 1, RAID 5, RAID 10 Configuration
• VIA VT1819 8-ch High Definition audio CODEC
• Compliant with HD audio specification
• Realtek RTL8111E Gigabit LAN
