Chapter 3
A85F2-A DELUXE (GOLDEN) USER MANUAL
42
fSouth Bridge
Scroll to this item and press <Enter> to view the following screen:
Restore AC Power Loss (Power Off)
This item enables your computer to automatically restart or return to its operating
status.
Audio Configuration
This item shows the information of the audio configuration.
Azalia HD Audio (Enabled)
This item enables or disables Azalia HD audio.
Azalia internal HDMI codec (Enabled)
This item enables or disables Azalia internal HDMI codec.
Press <Esc> to return to the Chipset Menu page.
Select AC Power state when
Power is re-applied after
a power failure.
Main Advanced Chipset M.I.B X Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
South Bridge
Restore AC Power Loss Power Off
Audio Configuration
Azalia HD Audio Enabled
Azalia internal HDMI codec Enabled
