A85F2-A DELUXE (GOLDEN) USER MANUAL

Chapter 1

System BIOS

Form Factor

• ATX Size, 305mm x 220mm

• AMI BIOS with 64Mb SPI Flash ROM

• Supports Plug and Play

• Supports ACPI & DMI

• Supports STR(S3)/STD(S4)

• Supports OC adjustment

• Supports Hardware monitor

• Audio, LAN, can be disabled in BIOS

• F7 hot key for boot up devices option

• Supports Over-Clocking

• Supports Four Display

• Supports GUI UEFI

• Supports Multi-Language
