Polski
Cechy
CPU
Chipset
• VIA K8T800 PRO & 8237
• Mostek północny: VIA K8T800 PRO
• Mostek południowy: VIA 8237
Pamięć
Możliwości
rozbudowy
• 1 złącze AGP 8X/4X
• 5 złącz PCI
Urządzenia
pamięc
masowej
• Obsługiwane przez VIA8237
- 4 urządzenia Ultra DMA133/100/66
- 2 urządzenia SATA
- Konguracje RAID 0 i RAID 1
• Obsługiwane przez SiS180
- 2 urządzenia Ultra DMA133/100/66
- 2 urządzenia SATA
- Konguracje RAID 0, RAID 1, RAID 0+1
IEEE 1394a
• Kontroler VT6307 IEEE1394a rmy VIA
• Obsługa 2 złącz IEEE1394a
Audio
• 6-kanałowy audio CODEC Realtek ALC655
• Zgodne z AC’97 2.3
Dual LAN
• Kontroller Marvel 88E8001 Gigabit LAN
• VIA VT6103L 10/100 Mbps Fast Ethernet PHY
Gniazda We/
Wy na tylnym
panelu
• 1 gniazdo klawiatury PS/2
• 1 gniazdo myszy PS/2
• 4 gniazda USB
• 2 złącza RJ45 LAN
• 1 port równoległy (LPT1)
• 1 port szeregowy (COM1)
• 2 gniazda Digital SPDIF (wyjście optyczne i koaksialne)
• 1 gniazdo wejściowe i 1 wyjściowe audio, 1 gniazdo wejściowe
mikrofonowe
• Gniazdo 939 dla procesorów AMD Athlon 64 FX
• Złącze szybkiego transpotu danych HyperTransport CPU
Interface
• Szybkość przesyłania danych 2000/1600/1200/800/400 MT/s
• Architektura pamięci dwukanałowej DDR
• Cztery 184 nóżkowe złącza DDR DIMM obsługujące do 4
GB pamięci
• Obsługa pamięci typu DDR400/333/266/200 i niebuforowanej
pamięci DDR SDRAM
Cechy BIOSu
• Award BIOS, zaopatrzony w 4Mb Flash ROM
• Obsługuje technologie Plug and Play 1.0A, APM 1.2, Multi Boot,
DMI
• Obsługuje technologię ACPI w wersji 1.0B
