ECS Elitegroup KV2 Extreme [83/111] Formfaktor

Deutsch

• 1 x 20-Pin ATX Netzteilanschluss & 4-Pin 12 V Anschluss

• 1 x Floppylaufwerkanschluss, unterstützt 360K ~ 2.88M Bytes, 3

Modus Festplatten oder LS120

• 3 x IDE Anschlüsse

• 4 x Seriell ATA Anschluss

• 2 x USB 2.0 Anschluss, unterstützt zusätzlich 4 USB Anschlüsse

• 2 x 1394a Anschlüsse

• 1 x EZ-Watcher Anschluss (Optional)

• 1 x SMBus Anschluss

• 1 x Schalter in der Frontabdeckung/LED-Anschluss

• 1 x Audioanschluss in der Frontabdeckung

• CD-Eingang-/AUX-Einganganschluss

• CPUFAN/NB_FAN/CASFAN Anschlüsse

• ATX-Größe

• 305mm x 244mm

Formfaktor

Internes I/O
