ECS Elitegroup KV2 Extreme [93/111] 규격

한 국 어

• 1 x 20 핀 ATX 파워 써플라이 커넥터 및 4 핀 12 V 커넥터

• 1 x 플로피 커넥터- 360K ~ 2.88M Bytes, 3 모드 FDD 또

는 LS120 지원

• 3 x IDE 커넥터

• 4 x 시리얼 ATA 커넥터

• 2 x USB 2.0 헤더, 추가적으로 4 개의 USB 포트 지원s

• 2 x 1394a 헤더

• 1 x EZ-Watcher 헤더 (선택)

• 1 x SMBus 헤더

• 1 x 앞 패널 스위치/LED 헤더

• 1 x 앞 패널 오디오 헤더

• CD 입력/AUX 입력 헤더

• CPUFAN/NB_FAN/CASFAN 커넥터

• ATX 사이즈

• 305mm x 244mm

규격

내부 I/O
