1-2
1.3 Feature Summary
CPU
Chipset
• VIA K8T800 PRO & 8237
• North Bridge: VIA K8T800 PRO
• South Bridge: VIA 8237
Memory
Expansion
Slots
• 1 x AGP 8X/4X slot
• 5 x PCI slots
Storage
• Supported by VIA8237
- 4 x Ultra DMA133/100/66 devices
- 2 x SATA devices
- RAID 0 and RAID 1 configuration
• Supported by SiS180
- 2 x Ultra DMA133/100/66 devices
- 2 x SATA devices
- RAID 0, RAID 1, RAID 0+1 configuration
IEEE 1394a
• VIA VT6307 IEEE1394a controller
• Supports 2 x IEEE1394a connectors
Audio
• Realtek ALC655 6-channel audio CODEC
• Compliant with AC’97 2.3 specification
Dual LAN
• Marvel 88E8001 Gigabit LAN Controller
• VIA VT6103L 10/100 Mbps Fast Ethernet PHY
Rear panel
I/O
• 1 x PS/2 keyboard
• 1 x PS/2 mouse connector
• 4 x USB ports
• 2 x RJ45 LAN connectors
• 1 x Parallel port (LPT1)
• 1 x Serial port (COM1)
• 2 x Digital SPDIF (Optical & Coaxial) out
• 1 x Audio port (Line-in, Line-out, Mic-in)
• Socket 939 for AMD Athlon 64 FX processor
• High-performance Hyper Transport CPU Interface
• Transfer rate of 2000/1600/1200/800/400 MT/s
• Dual-channel DDR memory architecture
• 4 x 184-pin DDR DIMM socket support up to 4 GB
• Support DDR400/333/266/200 unbuffered DDR
SDRAM
BIOS features
• Award BIOS with 4Mb Flash ROM
• Supports Plug and Play 1.0A, APM 1.2, Multi Boot, DMI
• Supports ACPI revision 1.0B specificaion
