ECS Elitegroup KV2 Extreme [95/111] 主機板尺寸

繁體㆗文

• 1個20針ATX 電源供應器連接器及1個4針12 V連接器

• 1個軟碟機連接器，可支援360K㉃2.88M位元組之3

Mode 軟碟機及LS120軟碟機

• 3個IDE連接器

• 4個序列ATA 連接器

• 2個USB 2.0接頭，可支援4個額外的USB埠

• 2個1394a接頭

• 1個EZ-Watcher接頭(可選)

• 1個SMBus接頭

• 1個前面板開關及1個LED 接頭

• 1個前面板音訊接頭

• CD音源輸入/AUX音源輸入接頭

• 處理器冷卻風扇/北橋晶片風扇/機殼風扇連接器

• ATX 尺寸

• 305mm x 244mm

主機板尺寸

內部輸出入

介面
