简体中文
功能摘要
CPU
芯片组
• VIA K8T800 PRO & 8237
• 北桥：VIA K8T800 PRO
• 南桥：VIA 8237
内存
扩展选项
• 1 个 AGP 8X/4X 插槽
• 5 个 PCI 插槽
存储
• 支持 VIA8237
- 4 个 Ultra DMA133/100/66 设备
- 2 个 SATA 设备
- RAID 0 和 RAID 1 配置
• 支持 SiS180
- 2 个 Ultra DMA133/100/66 设备
- 2 个 SATA 设备
- RAID 0, RAID 1, RAID 0+1 配置
IEEE 1394a
• VIA VT6307 IEEE1394a 控制器
• 支持 2 个 IEEE1394a 接口
音頻
• Realtek ALC655 6 声道音频编解码器
• 符合 AC’97 2.3 规格
双 LAN
• Marvel 88E8001 千兆 LAN 控制器
• VIA VT6103L 10/100 Mbps 高速以太网 PHY
后面板 I/O
• 1 个 PS/2 键盘接口
• 1 个 PS/2 鼠标接口
• 4 个 USB 端口
• 2 个 RJ45 LAN 接口
• 1 个并口 (LPT1)
• 1 个串口 (COM1)
• 2 个数字量 SPDIF（光纤和同轴）输出
• 1 个音频端口（线入、线出、麦克风入）
• 用于AMD Athlon 64 FX 处理器的 Socket 939 插座
• 高性能超级传输(HyperTransport)CPU 接口
• 传输速率 2000/1600/1200/800/400 MT/s
• 双通道 DDR 内存架构
• 4 个 184 线 DDR DIMM 插槽，内存最大可支持 4
GB
• 持 DDR400/333/266/200非缓冲DDR SDRAM
BIOS 功能
• Award BIOS (4Mb Flash ROM)
• 支持即插即用 1.0A、APM 1.2、Multi Boot、DMI
• 支持 ACPI Revision 1.0B 规格
