Български
Параметри
Процесор
Чипсет
• VIA K8T800 PRO & 8237
• Северен мост: VIA K8T800 PRO
• Южен мост: VIA 8237
Памет
Слотове за
разширяване
• 1 слот AGP 8X/4X
• 5 слота PCI
Възможности
за
съхраняване
на данни
• поддържани от VIA8237
- 4 устройства Ultra DMA133/100/66
- 2 устройства SATA
- RAID 0 и RAID 1
• поддържани от SiS180
- 2 устройства Ultra DMA133/100/66
- 2 устройства SATA
- RAID 0, RAID 1, RAID 0+1
IEEE 1394a
• Контролер VIA VT6307 IEEE1394a
• Поддръжка на 2 порта IEEE1394a
Аудио
• 6-канален аудио CODEC Realtek ALC655
• съвместимост със спецификацията AC’97 2.3
Dual LAN
• Мрежов контролер Marvel 88E8001 Gigabit
• Fast Ethernet PHY контролер VIA VT6103L 10/100 Mbps
Портове
Вход/Изход
на задния
панел
• 1 порт PS/2 за клавиатура
• 1 порт PS/2 за мишка
• 4 порта USB
• 2 конектора RJ45 LAN
• 1 паралелен порт (LPT1)
• 1 сериен порт (COM1)
• 2 цифрови изхода SPDIF (оптичен и коаксиален)
• 1 аудио порт (линеен вход/линеен изход/вход за микрофон)
• сокет 939 за процесор AMD Athlon 64 FX
• високопроизводителен интерфейс HyperTransport
• скорост на обмен на данни 2000/1600/1200/800/400 MT/s
• двуканална архитектура на паметта DDR
• 4 слота 184-pin DDR DIMM с поддръжка на общ капацитет
до 4 GB
• поддръжка на модули DDR400/333/266/200 небуферирана
DDR SDRAM
Параметри
на BIOS
• Award BIOS с 4Mb Flash ROM
• поддръжка на спецификацията Plug and Play 1.0A, APM 1.2,
Multi Boot, DMI
• поддръжка на спецификацията ACPI revision 1.0B
