Česky
Souhrn vlastností
CPU
Čipová sada
• VIA K8T800 PRO a 8237
• North Bridge: VIA K8T800 PRO
• South Bridge: VIA8237
Paměť
Rozšiřující
sloty
• 1 x slot AGP 8X/4X
• 5 x slot PCI
Disková
zařízení
• Podporovaná VIA8237
- 4 x zařízení Ultra DMA133/100/66
- 2 x zařízení SATA
- Kongurace RAID 0 a RAID 1
• Podporovaná SiS180
- 2 x zařízení Ultra DMA133/100/66
- 2 x zařízení SATA
- Kongurace RAID 0, RAID 1, RAID 0+1
IEEE 1394a
• Řadič VIA VT6307 IEEE1394a
• Podpora 2 portů IEEE 1394a
Zvuk
• 6kanálový zvukový kodek Realtek ALC655
• Splňuje požadavky standardu AC’97 2.3
Duální LAN
• Řadič gigabitový sítě LAN Marvel 88E8001
• Řadič sítě 10/100 Mbps Fast Ethernet, VIA VT6103L PHY
Vstupy/
výstupy
na zadním
panelu
• 1x konektor klávesnice PS/2
• 1x konektor myši PS/2
• 4x port USB
• 2x konektor LAN RJ45
• 1x paralelní port (LPT1)
• 1x sériový port (COM1)
• 2x digitální výstup SPRIT (optický a koaxiální)
• 1x zvukový konektor (linkový vstup/linkový výstup/mikrofon)
• Patice 939 pro procesory AMD Athlon 64 FX
• Vysoce výkonné rozhraní HyperTransport CPU
• Přenosové rychlosti 2000/1600/1200/800/400 MT/s
• Dvojkanálová paměťová architektura DDR
• 4 x 184kolíková patice DDR DIMM, podporující paměť do
kapacity až 4 GB
• Podpora pamětí typu DDR SDRAM 400/333/266/200, bez
vyrovnávací paměti
Vlastnosti
BIOS
• Award BIOS s 4 Mb Flash ROM
• Podpora Plug and Play 1.0A, APM 1.2, Multi Boot, DMI
• Podpora standardu ACPI verze 1.0B
