3-15
USB Resume from S3 (Disabled)
When set to Enabled, the system power will resume the system from a power
saving mode if there is any USB port activity.
VGA (Off)
When set to On, the system power will resume the system from a power saving
mode if there is any VGA activity.
LPT & COM (LPT/COM )
When this item is enabled, the system will restart the power-saving timeout counters
when any activity is detected on the serial ports, or the parallel port.
HDD & FDD (ON)
When this item is enabled, the system will restart the power-saving timeout counters
when any activity is detected on the hard disk drive or the floppy diskette drive.
PCI Master (OFF)
When set to Off, any PCI device set as the Master will not power on the system.
PowerOn by PCI Card (Enabled)
Use this item to enable PCI activity to wakeup the system from a power saving
mode.
Modem Ring Resume (Disabled)
Use this item to enable modem activity to wakeup the system from a power saving
mode.
• Power Button Lock for S3 (Disabled): When this item is disabled,
power button will not be locked.
PS2KB Wakeup Select (Hot key)
This option allows you to set hot key combination to turn on the system by
keyboard.
PS2KB/MS Wakeup from S1-S3 (Disabled)
This option enables you to allow keyboard or mouse activity to awaken the system
from power saving mode.
RTC Alarm Resume (Disabled)
When set to Enabled, additional fields become available and you can set the date
(day of the month), hour, minute and second to turn on your system. When set to
0 (zero) for the day of the month, the alarm will power on your system every day at
the specified time.
Press <Esc> to return to the Integrated Peripherals page.
